System

Main Processor

 Industrial-grade processor

Operating System

 Embedded Linux

Operating Interface

 Web; Local GUI

Quick Pick

QuickPick 2.0 AI by Recorder (Number of Channels)

 2 channels

Perimeter Protection

Perimeter Performance AI by Recorder (Number of Channels)

Advanced Mode: 2 channels, 10 IVS rules for each channel

General Mode: 8 channels, 10 IVS rules for each channel

Face Detection

Face Attributes

 6 attributes

Face Detection Performance of AI by Recorder (Number of Channels)

 2 channels(up to 12 face images/s each channel)

Privacy Protection

Privacy Protection Performance of AI by Recorder (Number of Channels)

1 channel

Face Recognition

Face Database Capacity

 Up to 10 face databases with 20,000 images.

Face Recognition Performance of AI by Recorder (Number of Channels)

 2 channels

SMD Plus

SMD Plus by Recorder

 16 channels: Secondary filtering for human and vehicle, reducing false alarms caused by leaves, rain and lighting condition change

SMD Plus by Camera

 32 channels

AI Video Quality Analytics

AI Video Quality Analytics by Recorder

 16 channels: Supports detecting brightness levels, color cast, defocus, overexposure, contrast levels, black and white

Scene Changing

Scene Changing by Recorder

 1 channel

Irregular Black Block Masking

Irregular Black Block Masking by Recorder

 1 channel

Audio and Video

Analog Camera Input

 16 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect

Camera Input

 1. CVI: 4K@25/30 fps; [email protected]/15 fps; 6 MP@20 fps; 5 MP@25 fps; 5 MP@20 fps; 4 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps; 720p@50/60 fps.

2. TVI: 4K@15 fps; 5 MP@20 fps; 4 MP@25/30 fps; 3 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps.

3. AHD: 4K@15 fps; 5 MP@20 fps; 4 MP@25/30 fps; 3 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps.

IP Camera Input

Up to 32 channels of IPC access

16 IP channels by default + 16 channels (analog channels are converted to IP channels)

Incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps

*After IP extension is enabled, Video Quality Analytics, Scene Changing, Face Recognition, Face Detection, SMD, Perimeter Protection, QuickPick 2.0 and Privacy Protection cannot be used.

Encoding Capacity

Encode Enhancement disabled：

Main stream:

4K@(1 fps–7 fps); 6 MP@(1 fps–10 fps); 5 MP@(1 fps–12 fps); 4K-N/4 MP/3 MP@(1 fps–15 fps); 4M-N/1080p/720p/960H/D1/CIF@(1 fps–25/30 fps)

Sub stream:

960H@(1 fps–15 fps); D1/CIF@(1 fps–25/30 fps)

Encode Enhancement enabled：

Main stream:

the 1st, 5th, 9th, 13th channel 4K@(1 fps–15 fps), others 4K@(1 fps–7 fps);

the 1st, 5th, 9th, 13th channel 6 MP@(1 fps–20 fps), others 6 MP@(1 fps–10 fps);

the 1st, 5th, 9th, 13th channel 5 MP@(1 fps–25 fps), others 5 MP@(1 fps–12 fps);

the 1st, 5th, 9th, 13th channel 4K-N/4 MP/3 MP@(1 fps–25/30 fps), others 4K-N/4 MP/3 MP@(1 fps–15 fps);

4K/6 MP@(1 fps–10 fps);5 MP@(1 fps-12 fps); 4K-N/4 MP/3 MP@(1 fps–15 fps); 4M-N/1080p/720p/960H/D1/CIF@(1 fps–25/30 fps)

Sub stream:

960H@(1 fps–15 fps); D1/CIF@(1 fps–25/30 fps)

*When Encode Enhancement is enabled, Video Quality Analytics, Scene Changing, Face Recognition, Face Detection, Perimeter Protection, QuickPick 2.0 and Privacy Protection cannot be used.

Dual-stream

 Yes

Video Bit Rate

 32 kbps–6144 kbps

Audio Sampling

 8 kHz, 16 bit

Audio Bit Rate

 64 kbps

Video Output

 1 HDMI, 1 VGA

HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720

VGA: 1920 × 1080, 1280 × 1024, 1280 × 720

*Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable.

Multi-screen Display

When IP extension mode not enabled: 1/4/8/9/16

When IP extension mode enabled: 1/4/8/9/16/25/36

Third-party Camera Access

 Panasonic; Sony; Hanwha; Axis; Arecont; ONVIF

Compression Standard

Video Compression

 AI Coding; Smart H.265+; H.265; Smart H.264+; H.264

Audio Compression

 G.711a; G.711u; PCM

Network

Network Protocol

 HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.)

Mobile Phone Access

 iOS; Android

Interoperability

 ONVIF 23.12 (Profile T; Profile S; Profile G); CGI; SDK

Browser

 Chrome; IE; Safari; Edge; Firefox

Recording Playback

Record Mode

 General; alarm; motion detection; intelligent; POS

Recording Playback

 1/4/9/16

Backup Method

 USB device and network

Playback Mode

 Instant playback; general playback; event playback; tag playback; smart playback

Storage

Disk Group

 Yes

Alarm

General Alarm

 Motion detection; alarm box; HDCVI alarm; camera external alarm; network alarm; PIR alarm

Anomaly Alarm

Error (no disk, disk error, low space, low quota space; network disconnection; IP conflict; MAC conflict); video loss; video tampering; camera offline

Intelligent Alarm

 Face detection; face recognition; perimeter protection; SMD Plus

Alarm Linkage

 Record; snapshot (panoramic); IPC external alarm output; audio; buzzer; log; preset; email

Ports

Audio Input

 1-channel RCA

16-channel BNC (Coaxial Audio)

Audio Output

 1-channel RCA

Two-way Talk

 Yes (share the same audio input with the first channel)

Disk Interface

 2 SATA ports. Each disk can contain up to 16 TB. This limit varies depending on the environment temperature.

RS-485

 1

USB

 2 (1 front USB 2.0 port, 1 rear USB 3.0 port)

HDMI

 1

VGA

 1

Network Port

 1 (10/100/1000 Mbps Ethernet port, RJ-45)

General

Power Supply

 12 VDC, 5 A

Net Weight

 1.80 kg (3.97 lb)

Gross Weight

 3.10 kg (6.84 lb)

Product Dimensions

 375.0 mm × 289.6 mm × 53.0 mm (14.76" × 11.39" × 2.09") (W × D × H)

Packaging Dimensions

 433.0 mm × 141.0 mm × 366.0 mm (17.05" × 5.56" × 14.41") (W × D × H)

Operating Temperature

 –10 °C to +55 °C (+14 °F to +131 °F)

Storage Temperature

 –20 °C to +60 °C (–4 °F to +140 °F)

Operating Humidity

 10%–90% (RH), non-condensing

Installation

 Desktop

Certifications

CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 FCC: Part 15 Subpart B
